Pulsating Vacuum Recangular Pressure Steam Sterilizer With the features of PLC and man-computer interface automatic program control.automatic temperature recording,vacuum drying,ect.it is suitable for hospitals,pharmaceutical factories,scientific research instiutes and other units to sterilize and dry clothing,dressings,meatl instruments,culture medium,dressungs,ect.
■ Main Parameters & Utilities
|
Design pressure |
0.245Mpa |
|
-0.095Mpa |
|
|
0.22Mpa |
|
0.4-0.6Mpa |
|
|
139℃ |
|
0.1-0.3Mpa |
|
|
134℃ |
|
0.5-0.7Mpa |
|
|
≤±1℃ |
|
|
■ Structure&Capability&Characteristics
·The box is designed,produced and tested strictly according to the《Steel Pressure Vessel》
·National patent door interiock
·National patent sealing technology of inner gas
·Reliable and stable micro-computer PLC+touch screen control,advanced function for function for recording,printing and storing
·Elegant stainless steel decorate cover
·The heat preservation layer is made by polyurethane material and pearl rock wool
·The GMP confirmation access is fixed on the equipment
·Pressure keeping inactivate system and inactivate container inactivate container inactivate system can be fixed according to the requirements of PⅣ、PⅤ lab
·B.D testing program is included in the equipment
■ Size&Utilities
Specifications
Model |
Overall Dimensions
L*M*H(mm)
Single/Double Door |
Chamber Size
L*W*H(mm) |
Sream Consumpyion
(kg/cycle) |
Power
(KW) |
Water Consmption
(kg/cycle)
|
Sterilization Time
(Minute) |
Net Weight
(kg) |
| YG-0.2 |
895*1220*1720 |
760*600*600 |
20 |
1.5 |
150 |
30 |
650 |
| YG-0.3 |
1195*1220*1720 |
1000*600*600 |
25 |
1.5 |
150 |
30 |
760 |
| YG-0.6 |
1245*1300*1880 |
1050*680*850 |
30 |
2.0 |
200 |
35 |
1100 |
| YG-0.8 |
1595*1300*1880 |
1400*680*850 |
35 |
3.0 |
250 |
40 |
1300 |
| YG-1.2 |
1695*1370*1960 |
1500*750*1100 |
40 |
3.0 |
300 |
45 |
1900 |
| YG-2.5 |
3195*1370*1960 |
3000*750*1100 |
80 |
4.5 |
450 |
50 |
2800 |
| YG-5.0 |
3635*1800*2200 |
3400*1000*1500 |
170 |
7.5 |
600 |
60 |
4500 |
